General Specification
Construction Material
Brass, Stainless Steel, Plastic
Installation type
Bath Mounted
Colour / Finish
Brushed Brass
Waste specification
Type
Bath Filler & Overflow
Slotted or Unslotted
Slotted
Connection
Threaded Nut
Function
Clicker
Length of Overflow Hose (mm)
600
Bath Filler & Overflow
Slotted or Unslotted
Slotted
Connection
Threaded Nut
Function
Clicker
Length of Overflow Hose (mm)
600
Tap / Shower specification
WRAS Approved
–
TMV Approved
0
Minimum Operating Pressure (bar)
0.5
Maximum Operating Pressure (bar)
5.0
Flexible Tails Included
0
Number of tap holes required
0
Handle Type
Lever
Swivel Spout
0
Inlet Connection
0
Outlet Connection
0
Tap Hole Diameter (mm)
0
Tap Type description
Manual Mixer
Includes Waste
0
Valve / Cartridge Type
0
Cartridge Spare code
0
–
TMV Approved
0
Minimum Operating Pressure (bar)
0.5
Maximum Operating Pressure (bar)
5.0
Flexible Tails Included
0
Number of tap holes required
0
Handle Type
Lever
Swivel Spout
0
Inlet Connection
0
Outlet Connection
0
Tap Hole Diameter (mm)
0
Tap Type description
Manual Mixer
Includes Waste
0
Valve / Cartridge Type
0
Cartridge Spare code
0
Flow Rates
0.2bar (l/min)
3.2
0.5bar (l/min)
7
1bar (l/min)
12
2bar (l/min)
17.7
3bar (l/min)
21.3
3.2
0.5bar (l/min)
7
1bar (l/min)
12
2bar (l/min)
17.7
3bar (l/min)
21.3
Product Transportation
Barcode: 5060964935539
Country of origin: CH
Commodity code: 8481801190
Product Measurements
Product Weight (KG): 0.435
Product Width (mm): See Line Drawing
Product Height (mm): –
Product Depth (mm): –
Product Length (mm): –
Primary Packed Measurements
Packaged Weight: 0.55
Packed Length: 24
Packed Width: 13.5
Packed Height: 10
Compliance DOP
HBDOC034 , HBDOC035
