General Specification
|
Construction Material |
Brass / Stainless Steel / Plastic |
|
Installation type |
Wall Mounted |
|
Colour / Finish |
Chrome |
Product Specification
Tap / Shower specification
|
WRAS Approved |
Yes |
|
TMV Approved |
0 |
|
Minimum Operating Pressure (bar) |
0.5 |
|
Maximum Operating Pressure (bar) |
5 |
|
Flexible Tails Included |
No |
|
Number of tap holes required |
N/a |
|
Handle Type |
0 |
|
Swivel Spout |
0 |
|
Inlet Connection |
0 |
|
Outlet Connection |
0 |
|
Tap Hole Diameter (mm) |
N/A |
|
Tap Type description |
Exposed Bar Valve |
|
Includes Waste |
Black |
|
Includes Waste |
Exposed Bar Valve |
|
Valve / Cartridge Type |
Thermostatic & Quarter Turn Cartridge |
|
Cartridge Spare code |
0 |
Tap / Shower specification
|
0.2bar (l/min) |
2.5 |
|
0.5bar (l/min) |
9.2 |
|
1bar (l/min) |
14 |
|
2bar (l/min) |
20 |
|
3bar (l/min) |
24.8 |
Showering specification
|
Anti-Scald |
Yes |
|
Shower Diverter function |
Yes |
|
Number of outlets |
2 |
|
Thermostatic Tempurature control |
Yes |
|
Cool Touch |
No |
|
Shower Handset funtions |
3 |
|
Shower Handset funtions |
0.5 |
|
Minimum Working Pressure |
5 |
|
Maximum Working Pressure |
5 |
|
Shape |
Round |
|
Pipe Centres (mm) |
150 |
|
Inlet Connection |
3/4 BSP |
|
Outlet Connection |
1/2 BSP Handset |
|
Adjustable |
Yes |
|
Adjustment (mm) |
803 - 1210 |
|
Handle Type |
Round |
Spares Codes
|
Diverter Spares |
XUSPARE002 |
|
Thermostatic cartridge Spares |
XUSPARE001 |
Product Transportation
Barcode: 5060500644031
Country of origin: CH
Commodity code: 8481809000
Product Measurements
Product Weight (KG): 3.5
Product Width (mm): 35.5
Product Height (mm): 11.8
Product Depth (mm): 0
Product Length (mm): 84.3
Primary Packed Measurements
Packaged Weight: 4.65
Packed Length: 86
Packed Width: 37
Packed Height: 50
Packaging Weights
Card (kg): 1.05
Paper (kg): 0
Wood (kg): 0
Plastic (kg): 0.002
Compliance DOP
HBDOC074 & HBDOC075
